Titanium Fiber Paper
Titanium fiber paper, made from compressed and flattened titanium fibers and sintered at a specific temperature, has a stable physical structure, high strength, high-temperature resistance, corrosion resistance, and excellent conductivity, making it widely used in various fields.
- Description
- Feature
- Specification
Titanium fiber paper, made from compressed and flattened titanium fibers and sintered at a specific temperature, has a stable physical structure, high strength, high-temperature resistance, corrosion resistance, and excellent conductivity, making it widely used in various fields.
Cetech's Titanium fiber paper has two different a porosity 45%~60% (low porosity) and 60%~75% (high porosity) and with available size in 20x20cm sheets for customer's selection.
Product Features:
Low resistance
Hydrogen generator applicable
Incompressible
Custom dimensions are welcome
| Properties | Unit | TiP025L | TiP040L | TiP060L | TiP080L |
|---|---|---|---|---|---|
| Hhickness | mm | 0.25 | 0.40 | 0.60 | 0.80 |
| Porosity | % | 45-60% | 45-60% | 45-60% | 45-60% |
*All data are the average values that do not represent specifications and tolerance.
| Properties | Unit | TiP025H | TiP040H | TiP060H | TiP080H |
|---|---|---|---|---|---|
| Thickness | mm | 0.25 | 0.40 | 0.60 | 0.80 |
| Porosity | % | 60~75% | 60~75% | 60~75% | 60~75% |
*All data are the average values that do not represent specifications and tolerance.
